AZON desktop DTF printing system

Entry-level DTF solution; Oeko-Tex certified.

The Azon Pronto A3 is suitable for beginners, career changers and professional textile finishers alike. This printer meets all requirements for small to medium print volumes. Thanks to the very simple setup and the Azon RIP software developed for this purpose, you can achieve excellent print results with this device with minimal effort.

transfer presses

The RGF sells Stahls and Hotronix® transfer presses exclusively in bundles with Ricoh/Azon DTF and DTG printing systems

View all

Azon textile printing systems

Digital textile finishing from Croatia

Print your unique designs directly onto any textile surface

Entry-level DTF solution; Oeko-Tex certified.
The Azon Desktop version of Direct to Film Printing technology. It allows you to print both dark and light garments with vibrant colors. A wide range of fabrics is covered, from 100% polyester to 100% cotton. Oeko-Tex certified.

How it works

In the Direct to Film (DTF) process, the desired motif for textile printing is first printed on a transfer film. A hot melt adhesive granulate is then applied and heated. This happens automatically in a single operation. The resulting transfer is later transferred to the textile using a hot press. The advantage of this process is its flexibility. A wide variety of textiles can be decorated: polyester, nylon, leather, but also classic cotton and mixed fabrics - without any pre-treatment.

Azon Pronto & Pronto Neon DTF printers for sheet goods

  • Azon Pronto

    Print area: 29.7 x 112 cm
    Material type: transfer film
    Printing technology: Ink-Jet (On-Demand Piezo)
    Drop size: Variable drop size 3.5 to 20 pictoliters
    Print resolution: 720 dpi, 1440 dpi
    Speed: A4 size 1440 x 720: 4 min 40 sec

    Ink:
    Type: Azon DTF ink
    Colors: CMYK + white
    500 ml ink system with circulation
    Curing: Heat Press/Tunnel (150 degrees C for 20-30 seconds)
    Software: RIP: Azon RIP

    Environmental conditions:
    temperature 15 to 30 degrees Celsius

    Energy consumption:
    Print mode 20 watts, ready mode 10 watts, sleep mode 4 watts, power off 2 watts

    Connectivity: USB

    Dimensions:
    Printer unit (L x W x H): 73 x 89 x 26 cm, weight: approx. 28 kg

  • Azon Pronto Neon

    Print area: 29.7 x 112 cm
    Material type: transfer film
    Printing technology: Ink-Jet (On-Demand Piezo)
    Drop size: Variable drop size 3.5 to 20 pictoliters
    Print resolution: 720 dpi, 1440 dpi
    Speed: A4 size 1440 x 720: 4 min 40 sec

    Ink:
    Type: Azon DTF ink
    Colors: Cyan, Fl-Magenta, Fl-Yellow, Black, White
    500 ml ink system with circulation
    Curing: Heat Press/Tunnel (150 degrees C for 20-30 seconds)
    Software: RIP: Azon RIP

    Environmental conditions:
    temperature 15 to 30 degrees Celsius

    Energy consumption:
    Print mode 20 watts, ready mode 10 watts, sleep mode 4 watts, power off 2 watts

    Connectivity: USB

    Dimensions:
    Printer unit (L x W x H): 73 x 89 x 26 cm, weight: approx. 28 kg

Azon Textile Printer - Features

  • Azon Pronto

    AZON PRONTO is a new generation DTF printer from a well-known Croatian manufacturer. AZON PRONTO offers an affordable and high-quality solution for those looking for digital printing and wanting to expand their production capacity. The Pronto is the ideal solution for a wide range of applications in fashion, soft signage, sportswear and personalized items.

  • Azon Pronto Neon

    Perfect for small to medium-sized businesses. Printing fluorescent magenta and yellow makes your images look more vibrant as they glow in the dark. Just like Pronto, Pronto Neon gives you the option to print on white, black and colored garments. You can print safely on both polyester and cotton. The Oeko-Tex certificate is included.

  • Cost-effective & low-maintenance

    Azon PRONTO has been carefully designed to keep maintenance to a minimum. With the Azon RIP software, every print is produced at a quality that far exceeds that of the competition, yet every aspect of the print is optimized to make it cost effective

  • Low maintenance - Low power consumption - Lower printing costs - Plug & Play

    - Every component of PRONTO™ is designed for durability.
    - Piezzo print head.
    - Long-lasting ink components.
    - Robust exterior.
