Mutoh UV printing systems


Mutoh was founded in Japan in 1952. The company is known for producing high-quality large format inkjet printers.
All Mutoh wide format devices share a strong focus on high quality. Mutoh offers wide format inkjet printers with piezo DOD (drop on demand) technology as well as cutting plotters for signs and banners and specialty and industrial applications.

"XPJ-461UF" and "XPJ-661UF", desktop UV-LED printers, are characterized by simple functionality and versatile printing.

The printers make it easy to print with real added value, such as excellent glossy finishes and texture decoration. They are suitable for personalized goods, industrial products, promotional items, small batch production and much more.

  • Small footprint, intelligent design model

  • Powerful model with increased productivity

  • Easy fine adjustment of the table height

    Easily print objects up to 70 mm thick using the manual adjustment knob

  • Automatic lifting of the table

    The automatic table lifting enables high-precision height adjustment and stabilizes the print quality.

  • table mechanism for various objects

    Removing the table allows printing on objects up to 150 mm thick.

  • rotating unit

    The ability to print 360° on cylindrical objects expands the range of your applications. (optional)

  • Wide open lid

    The expanded open space allows easy access for substrate positioning and maintenance.

  • original status

    Optimal height for operation with rolling stand (optional)

UV LED Local Dimming Control

A significant increase in productivity and minimized risk of dust contamination in glossy print areas.

The direct-to-object printers XpertJet 461UF and 661UF are equipped with a newly developed, segmented 2-inch wide UV lamp. The UV lamp has six different areas. Each lamp area can be controlled individually, which enables the production of multiple varnish effects in one printing process.

Glossy, semi-glossy and matt varnish effects can be produced in one print run on prints that combine CMYK with varnish or white with varnish. The result is a significant increase in productivity and a minimized risk of dust contamination in glossy print areas.

Mutoh local UV-LED Local Dimming Control - how it works

Product Highlights

  • Vacuum table holds media

    The vacuum table efficiently positions, holds firmly and smoothes even thin media. The suction power can be adjusted in five levels via the printer's control panel.
    (Optional for XPJ-461UF)

  • LED touch panel

    The highly visible electrostatic touch panel provides high display quality and improves the operation of the panel. It supports 8 languages.

  • maintenance mechanism

    The maintenance environment around the UV LED lamp has been renewed to make daily maintenance more efficient.
    New removable/replaceable lamp filters and lamp glasses make cleaning easier. In addition, a new print head improves beam stability and minimizes machine malfunctions.

  • MUTOH Original UV-LED inks

    MUTOH offers hard ink, UH21, and soft ink, US11. Both are environmentally friendly and VOC-free and can be used for heat-sensitive media. The US11 ink is UL GREENGARD Gold certified, meeting the most stringent standards for low VOC emissions. The UH21 ink achieves excellent adhesion*, especially for extruded acrylic. *It is recommended to perform an ink adhesion test before printing.

  • Bundled application software

    printing variable data

    The feature allows you to print personalized and unique data at once for one template.

    pattern for the density test

    The white and paint density test checks the correct amount of paint to achieve a glossy finish.

  • MUTOH Windows printer driver

    The included MUTOH Windows printer driver allows printing directly from the Windows PC without RIP software.
    The MUTOH Layer Editor allows multi-layer printing only with the Windows printer driver.

  • MUTOH Status Monitor[MSM]

    Significant improvement in response time when detecting print status
    Support for the First Time Installation Wizard
    Support of 10 languages ​​for all functions

  • obstacle detection system

  • XpertJet 461UF Brochures Download

    XpertJet 461UF data sheet

    XpertJet 461UF Fixing & Adhesive Mat Data Sheet

    XpertJet 461UF Vacuum Table Data Sheet

  • XpertJet 661UF Brochures Download

    XpertJet 661UF data sheet

    XpertJet 661UF rotary printing option data sheet

VerteLith™ - original RIP software from Mutoh

  • Get the most out of your Mutoh wide format printer with Mutoh VerteLith RIP software, which offers extended 6-channel support.

  • They are capable of handling a wide range of print jobs, including multi-layer applications requiring white and/or varnish layers.
    VerteLith™ is based on the Harlequin® Core, which ensures fast RIP processing times for both PDF and PostScript files as well as perfect processing of transparencies and spot colors.


    Download VerteLith brochure
